1 basic frame
2 19” aluminum vertical extrusions with T-sland increment slide for spring nut M5
2 multifunctional braces for cable clamping and universal mounting options
4 leveling feet (0-25 mm)
■ How supplied
Assembled
– With fixed 19” installation on the front for
components in acc. with IEC 297-3
– Flexible assembly of the built-in units with T-slot
At the front: 123 mm
■ Load rating
5000 N static
■ Tests
- Earthing in acc. with VDE 0100 T 540
- Vibration test in acc. with MIL-STD 810 E
■ Material/ Finish
- Basic rack, extruded aluminum, polished
- Corner piece, die-cast aluminum
- Multifunctional sheet steel, zinc-plated
Knürr Miracel® 19” Lab Rack, NO 19
with 2x 19” T-slot extrusion (basis for rack widths 600 / 700 / 800)
Lab Rack Aluminum
Lab Rack Steel
Ordering Information
Description:
• Produced in sizes 36U, 39U, 42U, and 52U
• Width: 600mm
• Types:
Single - one pair of 19" vertical extrusions
• Made of 2 mm sheet steel
• Frame made up of these parts:
a) Base
b) 19" vertical frame
c) Connecting material (screws included)
• Base can be equipped with castors (optional)
• Color powder coated RAL (standard RAL 7021)
19” FRAMES
