Knurr CoolDesk

The Comfort Desk Solution For Banks,
Insurance Companies And Process-Controlled Industries.
Efficient Water Cooling And Targeted Airflow Routing.

Knürr provides the perfect platform for setting up a scalable solution that also keeps pace with future challenges. Our thermal engineers and workstation experts implement test procedures to ensure that all applicable requirements and standards are complied with.

The innovative Knürr CoolDesk® unites Knürr expertise – know-how from the 19-inch technology area, thermal management and experience in the installation of modular workstations. These are the factors that enable the development of flexible and individual customer specific solutions.

Today’s working environment, being changed constantly by the rapid advances in IT technology, presents Knürr with the continuous challenge of further developing special workstation environments that incorporate computing units, communication electronics and screens, and which help to keep rooms at optimum thermal conditions.

Comfort Desk Solution
For Flexible Technology Integration

•Height adjustment with easier and more cost-effective water supply and drainage.
•Significantly reduces the
demands on room cooling.

Energy/power-saving

• Every system can be separately fed, controlled and checked.

•Two independent heat
exchangers enable requirements-
oriented usage that
significantly reduces operating costs!

Closed air circulation for cooling electrical components in the under desk installation space

individually
adjustable air
outlets

Targeted airflow
routing in
the underdesk
installation
space

Targeted airflow
routing at
monitor level

Targeted airflow
routing for thermally
managing
the room

Open air circulation for the monitor and room cooling/thermal management

•At monitor level:
Issuing the cooled air via individually
adjustable air outlets
enables optimum monitor
cooling.

•Room climate:
The room temperature can be
specifically influenced by the
warm airflow routing. The
cooling system does not apply
for the monitors alone – it also
applies for the complete room
climate.

Energy efficiency
Targeted airflow routing

            •In the installation space:
             The cooled air is routed to the
             front of the computer where
             the air is optimally pulled in
             and can be taken into the circulation.
             Knürr CoolDesk® provides an
             ideal temperature for electrical
             and electronic devices with
             minimum energy consumption.

Flexible arrangement
possibilities in the room
From individual standard
modules through to customerspecific
process environments –
numerous integrated solutions
are possible for the control
room.

Ergonomics and
quality design
•The demands on an ultramodern
and process-oriented
work environment are fully
satisfied with the integration
of occupational therapy
know-how.
•Low-noise working ensured by
sound absorption at the workstation.
Specially developed
acoustic concept (max. 35 db
(A)) ensures pleasant environment
and working conditions.
•Incorporation of customerspecific
design requests.
•Optionally height adjustable.
Individual work height guarantees
dynamic changing between
standing and sitting.
•Additional monitor level
possible

Investment security
•Long life service, high
quality, perfected and
modern design.
•System modularity enables
flexible retrofitting.
•Intelligent cable management:
Dust-protected cable
management with brush strip
across the entire desk width
and a spacious cable duct in
the installation space.
•Expertise in thermal management and long-standing experience gathered over many
years.

Operational reliability
•Monitoring of:
- Temperature
- Leakages
- Smoke
•Protected technology in the
workstation environment
optimizes the process flows,
e.g. in dealer rooms or control
centers.

Doubleworkstation
with vertical airflowrouting

•Solution via chiller, connection to a complete Knürr supply system.

•Only one water flow required!
No airflow routing. This saves
space, cost and energy.

•Separate heat exchanger in
superstructure and underdesk
installation space.

•Possibility of connecting to
existing piping in the raised floor.

•Connection to building system
with the option of integrating
the Knürr CoolTrans® for
constantly even water supply.

Monitor cooling andwork area/room cooling

Singleworkstation
with horizontal airflowrouting

Emerson Network Power is the global technology leader in numerous areas, and a recognized expert in helping to secure business-critical processes, and therefore contributes to “business-critical continuity.”
A whole range of the most varied applications, including the tried and tested Knürr rack system solutions and the accompanying thermal management, ensures the required network stability with maximum technological adaptability at the same time.

Knürr system solutions in the world of information and network technology are part of an adaptive architecture from Emerson Network Power, which flexibly adapts to changes concerning security, high-density and all associated capacities. Companies are provided sustainable and long-term benefits from the high IT availability, operative flexibility and impressive reduction in investment and operating costs.

The Knürr Technical Furniture business unit develops, produces and distributes technical workstation systems for control consoles, operation control centers and electronics labs, as well as mobile equipment carriers for the automotive and medical technology industries.

Knürr AG is recognized around the world as one of the leading developers, manufacturers and distributors of rack and enclosure platforms in the indoor and outdoor area, including all relevant active/passive components in 19” construction and the technologies associated with it. Knürr is part of Emerson Network Power.

Knürr is certified in accordance with EN ISO 9001 and EN ISO 14001, and its quality management continuously guarantees the highest standards in all areas of the company.
