Talk & Trace™ TM110
    The hands-free personal communications set that can be used in any
wiring environment

• Clear, clean voice communication without interference or “dropouts” over coaxial cable, audio cable, speaker wire, telephone lines, or common electrical wiring
• Trace wires simultaneous while talking
• Range up to 5,000 feet, depending on cable used
• Up to 4 units can be linked together for party line use
• Full ring alert function

TM110 includes:
• Talk & Trace™, 2 units
• Mini headset LB40, 2 units
• 48" cord set, RJ11 to alligator clip set LB31B, 2 pieces
Talk & Trace™ Accessories
TM24 Test lead assembly, 24", banana plug to test probes.
TM48 Test lead assembly, 48", banana plug to test probes.
PC110 Pouch for Talk & Trace™
Associated Kits with Talk & Trace™ is on page 14. Kit number: KP110.
Associated Kits with Ranger™ are on pages
15–19. Kit numbers: KP402-A, KP403,
KP407, KP506-A, KP602-A, KP605-A.
LB255 includes:
    • Ranger™ with ADLI
    • Bed of nails cord set LB35
    • Mini headset LB40
    • Nylon pouch LB80
• Microphone Mute
• Last Number Redial—24 Digits
• Electronic Ringer
• Amplified Line Monitor for volume
        levels comparable to “off hook”
        operation
• Modular cord set attachment
• Headset for hands-free use
• Auto power-off eliminates dead
        batteries
• LCD display shows—
    – On-hook voltage
    – Number dialed
    – Off-hook current
    – Set-up information
    – Stored numbers
    – Battery condition
    – Continuous polarity indication
    – Caller ID
    – Call waiting/Caller ID
    – Caller ID errors

Ranger™ DSL-Safe Test Set LB255
    The most powerful test set we build, it incorporates a built-in amplified speaker, as well as new, advanced features unavailable on any other test set in the market.

• DigiView™—DTMF Decode
        allows you to see the digits
        as a dial-out is in progress
        and capture those digits.
• ADLI™ Auto Dial Line Identification—
        Inbound and outbound
        line identification with caller
        ID testing.
• Trafixguard™—Senses digital
        lines and identifies underand
        over-voltage conditions.
        Totally DSL safe!
• Insta-Talk™ Amplified Speaker
        with simultaneous intercom
        capability for talking while
        testing.
• Amplified Speaker with three
        volume levels
• Enhanced Memory Dialing—
        alpha and numeric capability
• Eight-number Memory
• Tone and Pulse Dialing


               ABU DHABI                  DUBAI                       JAFZA                                                 MUSCAT                                                   DOHA

UAE +971 2 5557351    +971 4 3352995    +971 4 8831401        OMAN  +968 24 750205        QATAR   +974 44150543

Associated Kit with Resi-Talker™ is on page 19. Kit number: KP312.
LB300 includes: • Resi-Talker™ • Alligator clips cord set LB31B
Test Set Accessories
for Lil’ Buttie™, Lil’ Buttie Pro™, Resi-Talker™,
and Ranger™

LB10B
LB20B
LB25

LB30B

LB31B
LB35

LB40B
LB45B
LB60B
LB64
LB66
LB68
LB70B
LB75
LB80
LB85B
PC300


TP21






48" cord set, RJ11 to alligator clip set
48" cord set, RJ11 to piercing clip set
48" cord set, premium, RJ11 to piercing
clip set
48" cord set, RJ11 to bed of nails with
strain relief
48" cord set, RJ11 to alligator clip set
48" cord, premium, RJ11 to bed of nails
and piercing clip set
Mini headset with microphone
Deluxe headset
Two-piece belt clip
4-position modtest adapter
6-position modtest adapter
8-position modtest adapter
AT&T hook/clip assembly, yellow
Telco clip
Nylon pouch holds one telephone test set
AT&T hook/clip assembly, blue
Nylon pouch holds all three:
telephone test set, tone tracer and
tone generator
No-fault RJ12 connector. Use on both
RJ11 and RJ45 jacks, 6-conductor. Uses
standard telco crimper
• Modular Cord Set Attachment
• Low Battery Indicator
• Headset Jack
• Battery Powered Monitor Mode
   with auto power off on dead
   lines or when disconnected
Resi-Talker™ Test Set LB300
    Our most economical test set for basic telephone system work.

• Tone and Pulse Dialing
• Microphone Mute
• Last Number Redial—32 Digits
• Continuous Line Polarity Indication
    (TALK or MONITOR)
• Electronic Ringer
• Amplified Line Monitor for volume levels
comparable to “off hook” operation

• Modular Cord Set Attachment
• Low Battery Indicator
• Headset Jack
• Battery Powered Monitor Mode
   with auto-off on dead lines or
   when disconnected
Lil’ Buttie™ Test Set with bed of nails
cord set and AT&T snap clip LB115
Lil’ Buttie™ Test Set with
bed of nails cord set LB110
Includes:
• Lil’ Buttie™
• Bed of nails cord set LB35
• Mini headset LB40
• AT&T hook/clip assembly, yellow LB70
• LCD Display shows—
– On-hook voltage
– Number dialed
– Off-hook current
– Set-up information
– Stored numbers
– Battery condition
– Continuous polarity indication
– Caller ID
– Call waiting/Caller ID
– Caller ID errors
– Tone and Pulse Dialing
Lil’ Buttie Pro™ Test Set LB220/LB230
    Telephone test set with LCD readout and voltmeter.

• Five Number Memory
• Technical Support Number
   programmed into memory dial
• Tone and Pulse Dialing
• Microphone Mute
• Last Number Redial—19 Digits
• Electronic Ringer
• Amplified Line Monitor for
   volume levels comparable
   to “off hook” operation
• Modular Cord Set Attachment
• Headset for hands-free use
• Auto Power Off eliminates
   dead batteries

Includes:
• Lil’ Buttie™
• Bed of nails cord set LB35
• Mini headset LB40
• Metal belt clip
Includes:
• Lil’ Buttie Pro™
• Bed of nails cord set LB35
• Mini headset LB40
• AT&T hook/clip assembly, yellow LB70
Includes:
• Lil’ Buttie Pro™
• Bed of nails cord set LB35
• Mini headset LB40
• Two-piece belt clip LB60
Includes:
• Lil’ Buttie™
• Piercing clip set LB25
• Mini headset LB40
• Metal belt clip
Lil’ Buttie Pro™ Test Set with bed of
nails cord set and AT&T snap clip LB230
Lil’ Buttie Pro™ Test Set with
bed of nails cord set LB220
Lil’ Buttie™ Test Set with
piercing clip set LB100
Associated Kits with Lil’ Buttie Pro™ LB220 are on pages 14–18.
Kit numbers: KP220, KP400, KP401, KP406, KP500, KP501, KP600, KP601.
Associated Kits with Lil’ Buttie™ LB110 are on page 14. Kit numbers: KP200, KP300.
Lil’ Buttie™ Test Set LB100/LB110/LB115
    Hands-free test set with headset. At half the size and half the weight,
it establishes a new standard in field test sets.

• Tone and Pulse Dialing
• Microphone Mute
• Last Number Redial—32 Digits
• Continuous Line Polarity Indication
   (TALK or MONITOR)
• Electronic Ringer
• Amplified Line Monitor for volume levels
   comparable to “off hook” operation
