Latch-Test™ Security/Alarm Tone Generator TG300
A combination advanced tone generator and continuity tester for sensors, switches and circuits used in security/alarm systems. Tone Generator Features
• Two tone amplitude levels—normal and half
• Half amplitude is unbalanced for stronger signal on twisted pairs, CAT 5/6 cables
• Three distinctly different tones selected from front panel
• Constant Amplitude Signal over life of battery for 100% signal strength
all the time
• Auto-off of tone after 3 hours—no dead battery if left on
Continuity Tester Features
• Four continuity modes—Normally Open (NO), Normally Closed (NC) indication modes, either latched or direct reading
• Audible and visual indication of continuity results; audible can be turned off
• Auto-off after 30 minutes of inactivity
General Features
• Compact, durable case with recessed control panel
• High-quality silicon alligator-clips cable permanently attached
• RJ jack allows use of modular cable without adapters
• Battery low indicator
• Lanyard attachment loop
Turbo-Tone™ High-Powered Tone Generator TG200/TG201
The most powerful tone generator you can put in your pocket.
It generates as much as 700% more power than standard tone generators!
• Extra-long distance capability. Detect tone up to 20 miles away.
• Constant amplitude output for 100% signal strength all the time, no signal decrease as battery discharges
• Easily hear signal through walls and enclosures
• Multiple tones and power levels for all applications—
CAT 5/6, signal wire, coax, telephone cable
• Unbalanced tone mode for longer distances on CAT 5/6 cables
• Auto-off for battery conservation
• Full talk battery and constant polarity check
• Includes adapter cables and carrying case
• Available with alligator clip set or bed of nails cord set
UAE +971 2 5557351 +971 4 3352995 +971 4 8831401 OMAN +968 24 750205 QATAR +974 44150543
“No-Twist” telephone handset cord adapter
18" cable assembly, “F” push-on plug to RJ11 plug
Pouch holds one tone tracer
Pouch holds both tone tracer and tone generator
Pouch holds all three:
telephone test set, tone tracer and tone generator
24" cord set, RJ11 to alligator clip set
24" cord set, RJ11 to bed of nails cord set
7.5" cable assembly, with no-fault RJ12 connectors
for RJ11 or RJ45 jacks.
Round tip for tone tracer
Paddle-style tip for tone tracer
LB22
LB34
PC100
PC200
PC300
TG10
TG20
TP20
TT30
TT35
• 7.5" cable assembly with no-fault RJ12 connectors for RJ11 or
RJ45 jacks TP20 • Cord set with alligator clips TG10
Resi-Toner™ Home Networking Tone Generator TG400
A full-function tone generator with unique features designed to further test connections on telephone systems and speaker installations. Find your outlets and assure your connections with Resi-Toner™.
• “Powers-up” installed telephone lines under actual load conditions with a simulated dial tone to check connectivity and proper wiring configurations without a service connection
• Full-feature tone generator with 3 different tone sounds and continuity test
• Generates a unique tone sequence for testing speaker installations by
“popping” speakers—will work with either AC- or DC-coupled speaker types
• Requires 9 volt battery (not included)
Associated Kits with Tone Tracer are on pages 13–19. Kit numbers: KP100, KP101, KP105, KP106, KP150, KP300, KP400, KP401, KP402-A, KP403, KP406, KP407, KP450, KP500, KP501, KP506-A, KP600, KP601, KP602-A, KP605-A.
On page 4: LanScaper™ Kit NT750.
Kit numbers: KP312, KP313, KP314.
Associated Kit with Tone Generator TG101 is on page 13. Kit part number: KP101
Associated Kits with Tone Generator TG100 are on
pages 13–19. Kit numbers: KP100, KP300, KP400, KP402-A,KP500, KP501, KP506-A, KP600, KP601, KP602-A, KP605-A.
TG100 includes: • Tone Generator • Cord set with
alligator clips TG10 • 7.5" cable assembly with no fault RJ12 connectors for RJ11 and RJ45 jacks TP20
TG101 includes: • Tone Generator • Cord set with bed of nails TG20 • 7.5" cable assembly with no-fault RJ12 connectors for RJ11 and RJ45 jacks TP20
TT300 includes: • Resi-Tracer™• Round tip TT30
TT100 includes: • Tone Tracer • Round tip TT30 • Paddle-style tip TT35
Our most popular tone generator, with advanced features.
• Three built-in tones, one steady and two warbles, for multiple lines testing
• Constant tone amplitude over life of the battery gives accurate and traceable
tones, even at the end of battery life
• Two tone amplitude levels, normal and half, let the user extend the tone reach
• Auto-off protects the battery life
• Tone may be added to any mode for using phone sets without monitor mode
• Power-saver feature in continuity mode preserves battery life
• Separate Talk Battery mode increases voltage and power for test sets
• Modular jack allows multiple cord sets to be used for different applications
Resi-Tracer™ Tone Detector and Cable Finder TT300
Resi-Tracer combines unique new features for tracing telephone, network, coax, and audio cable with special functions for finding and phasing speakers and testing telephone systems.
• Traces all types of cable: CAT 5/6, telephone, coax
• Audible and visual tone location indication
• Senses Speaker Phasing when used with Resi-Toner™ (TG400)
• Traces coax cable on active systems to eliminate shutdowns
• POTS testing with monitor mode and off-hook listening mode
Tone Tracer High-Sensitivity TT100
Sets a new standard for field service professionals. Due to its slim, ergonomic design, as well as balanced weighting, it is the most comfortable tracer available. It can be used with either a wearable headset or a standard cell phone headset. Quick-change tips for easier in-field use. Includes low battery indicator.
